Integrating pumped hydro with compressed air energy storage

A group of Chinese researchers has made a first attempt to integrate pumped hydro with compressed air storage and has found the latter may help the former to better deal with large head variations.
Schematic of the system
Schematic of the system | <i>Image: Harbin Institute of Technology</i>

Researchers from China’s Harbin Institute of Technology proposed to combine pumped hydro storage systems with compressed air energy storage (CAES) technology in an attempt to address a well-known issue of pumped hydro schemes – dealing with large head variations in hydraulic machinery.

“We have designed a novel pumped hydro compressed air energy storage system integrating pumped hydro storage, compressed air energy storage and hydraulic potential energy transfer technologies,” the research’s corresponding author, Deyou Li, told pv magazine. “We have also analyzed the system’s composition and operation principle, as well as the thermodynamic model of each module. Its correctness was verified by comparing our results with the existing literature data.”

In the paper “Energy and exergy analysis of a novel pumped hydro compressed air energy storage system,” published in Energy, the research group explained that the system works through multi-cycle charging and discharging processes. It comprises a pumped storage unit, a reversing valve, a spraying device, water hydraulic cylinders, an air storage tank, a pump, a water pool, and several valves.

In the charging phase, the system extracts water from the water pool through hydraulic machinery. The water is then pushed into the air storage container for air compression. During discharging, the air inside the air storage container expands, and the water
coming from the container is injected into the hydraulic machinery for electricity generation.

“The proposed system can store and release energy by charging and discharging, enabling it to perform peak-shaving and valley-filling functions,” the academics said. “When the electrical load is small, the surplus electrical energy is absorbed by the pumped storage unit and converted into internal energy of the compressed air for storage. Conversely, the system supplies power to the grid.”

The system also uses a spraying device to enhance heat transfer between the air and water in the tank to achieve near-isothermal compression and expansion.

“When the spray device is not used, the air temperature rises to 36 C during charging and decreases to 6.4 C during discharging,” the group explained. “When spraying, the variation in air temperature under the charging, standby, and discharging conditions significantly decreases. The maximum value of air temperature during charging reduces to 28.4 C and the minimum value of air temperature during discharging increases to 13.2 C.”

The scientists tested the proposed system configuration through a series of simulations and assumed the system to have a capacity of 1 MW. They calculated a charging time of 31.1 minutes and a discharging time of 23.1 minutes.

The analysis demonstrated that the water pressure potential energy transfer module adopted in the system can effectively convert the pressure variation of nearly 1.6 MPa in the air storage tank to a head variation of 58.5 m during pumping and 48.2 m during power generation of the pumped storage. It also showed that the pumped storage unit has the highest energy waste and is the section of the system that needs to be further optimized within a general approach aimed at reducing the system’s complexity.

“In future studies, the number of energy transformations in the proposed system will be further reduced,” the researchers concluded. “Subsequently, an experimental platform will be developed to verify the technical feasibility of the proposed system and reveal the effects of key design parameters, such as the initial pressure, termination pressure, volume of the air storage tank, and variable pressure ratio, on the operational performance of the system.”
